Desai J, Smit C (2018) The Use of Allogenic Human Demineralised Humerus as a Mandibular Reconstructive Conduit: A Novel Technique. Int Arch Oral Maxillofac Surg 2:018. 10.23937/iaoms-2017/1710018

BRIEF REPORT | OPEN ACCESS DOI: 10.23937/iaoms-2017/1710018

The Use of Allogenic Human Demineralised Humerus as a Mandibular Reconstructive Conduit: A Novel Technique

Jameel Desai1* and Coelette Smit2

1Consultant and Senior Lecturer, Department of Maxillofacial and Oral Surgery, University of Pretoria, South Africa

2Consultant and Director, Advanced Orofacial Surgery, Rosebank, Johannesburg, South Africa


Reconstructing mandibular defects after trauma or ablative surgery is reliably done with compressed autogenous cortical and cancellous particulate bone. We present the use of a demineralised allogenic humerus shaft as a conduit for the autogenous particulate bone. This technique simplifies surgery, is less morbid for the patient, the graft also resembles the remaining native mandible and reduces overall treatment cost for such patients.


Mandible reconstruction, Allogenic humerus, Demineralised, Conduit


The reconstruction of the human mandible after ablative surgery presents several challenges. Perhaps one of the more challenging aspects is the choice of preferred reconstruction technique. The work being done in the field of tissue engineering shows great promise, but a reliable and reproducible engineered graft for mandibular defects has to date not materialized [1]. Many surgeons favour a free vascularised fibula graft whilst others, an autogenous non vascularised graft. Our preference for small to moderate defects after benign neoplastic tumour resection, remains the latter. Autogenous compressed particulate cortical cancellous bone (PCBM) harvested from the anterior ilium is our technique of choice. Containing this type of graft in the resection bed is problematic as it tends to disperse and lose its intended form [2].

The use of an allogenic carrier is well documented in the literature, with split rib, fibula and mandible being well documented [3]. We believe that the use of an allogenic demineralised humerus (ADH) is desirable, and that its in vivo use as a conduit for PCBM is not widely reported in the literature.

Material and Method

Patients that have undergone partial mandibular resection for benign neoplastic pathology, were candidates for reconstruction using a combined ADH conduit with PCBM. The ADH shafts were provided by BONE SA (Bramley, Johannesburg, South Africa); comprising two lengths, namely 10 cm for unilateral reconstruction and 20 cm for larger defects that include the symphysis. The ADH shafts are quality controlled then given a 10% hydrochloric (HCl) acid bath, neutralised with a 0.1% sodium bicarbonate (NaHCO3) solution and rinsed in sterile water before being packaged (Figure 1). The ADH has a recommended shelf life of two years and requires refrigeration.

Figure 1: The prepared and packaged ADH shaft. View Figure 1

The ADH shaft is hollowed out to a cortical thickness of about 3 mm and then perforated multiple times with a round burr, all the while being kept moistened with Lactated Ringer's solution (Figure 2). The ADH shaft is then filled like a sausage with PCBM, harvested from the anterior ilium (Figure 3) and this allogenic autogenous composite bone conduit is grafted into the defect site (Figure 4). The conduit was grafted immediately after resection, making this a single staged surgery with no need for interim spacer [4].

Figure 2: A hollowed out and perforated ADH conduit seen alongside a syringe of compacted PCBM harvested from the anterior ilium. View Figure 2

Figure 3: The ADH conduit being filled like a sausage, with the PCBM. View Figure 3

Figure 4: The prepared ADH conduit seated within the graft bed post partial resection of right mandible. The reconstruction plate to which the graft is secured is clearly visible. View Figure 4


The allogenic humerus is provided by BONE SA (Bramley, Johannesburg, South Africa) a bio-medical company that acquires its tissue from donors. The humeral shafts are used in orthopaedic applications where they are grafted as spinal struts, and is this an existing product in their range. Allogenic humerus takes two weeks to prepare, and once packaged may be stored for up to 2 years in Refrigerator, which means that cases may be planned on a whim. This bone in non-immunogenic and carries no risk for transmission of infectious disease as it is Gamma irradiated (25 kGy) further, all donors are tested for HIV; Syphilis; Tuberculosis and Hepatitis B & C. A demineralised humerus has dimensions that mimic the mandible in its height and width. The ADH is pliable and hence may be bent and moulded along the natural curvature of a mandible. It also contains the PCBM preventing displacement and reducing the required volume. The semi-rigid, shape and volume, prevents tethering down of the soft tissue and this results in a widened crest for future dental implant placement. The use of circumferential wire around the ADH and reconstruction plate, allows for close adaptation between the plate and the graft. Perhaps the most persuasive reason for the use of ADH is that it is osteoconductive, but the demineralisation exposes some osteoinductive bone proteins too [5]. There is no appreciable cost increase with the use of the ADH; 10 cm length (USD 140) and 20 cm (USD 280).


In our opinion, the use of an ADH shaft as a reconstruction conduit to carry PCBM may be exploited to the benefit of patients, as it simplifies the reconstruction of the mandible. The technique saves time intra-operatively, and results in a reconstruction that closely resembles the remaining native mandibular bone.

Conflicts of Interest



No funding of any nature was received.


No consent was required.


  1. Meijer GJ, de Bruijn JD, Koole R, van Blitterswijk CA (2008) Cell based tissue engineering in jaw defects. Biomaterials 29: 3053-3061.
  2. Ferreti C, Muthray E, Rikhotso E, Ryneke J, Ripamonti U (2016) Reconstruction of 56 mandibular defects with autologous compressed particulate corticocancellous bone grafts. Br J Oral Maxillofac Surg 54: 322-326.
  3. Marx RE (2012) Maxillofacial Reconstruction Using Cancellous Cellular Marrow Grafts. In: Bagheri SC, Bell RB, Khan HA. Current therapy in oral and maxillofacial surgery. Elsevier, Missouri, 545-557.
  4. Ferretti C, Rikhotso E, Muthhray E, Reyneke J (2013) Interim reconstruction and space maintenance of mandibular continuity defects preceding definitive osseous reconstruction. Br J Oral Maxillofac Surg 51: 319-325.
  5. Toricelli P, Fini M, Giaveresi G, Giardino R (1998) In vitro osteoinduction of demineralized bone. Artif Cells Blood Substit Immobil Biotechnol 26: 309-315.
